This Diagram shows Complete Electrical House wiring. Nowadays perfect house wiring is a good electrical term for us. These days we can not stay any time without electricity. For this reason, we need connect electricity in our houses, office, industries, etc. We need perfect wiring in our house. In this diagram, we describe how to connect a DP MCB with a light, fan, and switch regulator.

Diagram of Complete Electrical House wiring

Components Need for this Project:

You can get the components from any of the sites below:

  1. DP MCB [See Buy Click Amazon]
  2. 2 Way Switch [See Buy Click Amazon]
  3. Regulator [See Buy Click Amazon]
  4. Ceiling Fan [See Buy Click Amazon]
  5. Light [See Buy Click Amazon]
*Please note: These are affiliate links. I may make a commission if you buy the components through these links. I would appreciate your support in this way!


Read Also:

Components used to make the House wiring:

01. DP MCB

Fig 2: DP MCB
Double pole MCB can control two wires. This circuit breaker is generally used in single-phase electric lines. Double pole MCB circuit breaker input has two wires supply two wires and an output. In a single-phase line, A double-pole MCB circuit breaker is used to give good production. This circuit breaker is provided through phase and neutral circuit breaker, it is very safe. This circuit breaker is preferred for home appliances. A DP MCB usually trips for 2 reasons 1. Overload 2. Short circuit.

02. 2 Way Switch

2 Way Switch
Fig 3: 2 Way Switch
The two-way switch is a type of multiway switch. Multiway switches have more points and can be controlled in multiple ways simultaneously. The middle connection normally goes to the load and the two side connections act as switches. Again, the opposite is also true if it is used in the lamp connection.It is a type of switch that has three wire connections. And it really has no off or on. Both sides can be turned on or off depending on how you connect one to the other. The two-way switch is a type of multiway switch. Multiway switches have more points and can be controlled in multiple ways simultaneously. Two Way Switch has three wire connection system.

03. Regulator

Fig 4: Regulator
Reduces fan speed by switching on and off. Reducing the speed of the fan, the power Consumption is also Reduced. It is basically a wire wood resistor-based regulator. The large regulators that were used in the past took up more than half of the switchboard space and were very hot. It looks very small in size. Almost equal to a switch. Electrical regulators are basically made by winding copper wire on an iron core. As Electricity Travels Long Distances Through These Wires, Some of The Electrical Energy is Converted Into Heat Energy.

04. Ceiling Fan

Ceiling Fan
Fig 5: Ceiling Fan
The main driving force behind all ceiling fan systems is the motor used inside the fan. We can also compare it with the soul of a fan. This motor converts the supplied electrical energy into mechanical energy which turns the ceiling fan and gives us air. When current is supplied, the magnetic field formed on the positive half-cycle becomes the reverse magnetic field on the next negative half-cycle. The magnitude part does not rotate and the capacitor is converted to a phase when it is connected to a phase motor or ceiling fan with a helical coil or stationing coil. When power is supplied there is a magnetic difference between the phase currents and the coils (acting as two phases) so that the motor or fan rotates.

05. Light

CFL light
Fig 6: Light
CFLs work in a completely different way from ordinary lamps, they work by using a different process called fluorescence rather than generating light from heat. A typical light bulb wastes 90% of energy and converts only 10% of energy into light, this is where CFL has the biggest advantage. CFL- Curved or conical glass tube filled with argon and a small amount of mercury vapor. The inner wall of the glass is coated with fluorescent material. CFL- It is manufactured using the principle of creating fluorescent light. CFL- Originally white in color but now the construction and use of CFLs producing colored light has become popular.

Thank You for visiting the website. Keep visiting for more Updates.


Frequently Asked Questions

Which system is used in house wiring?

The ring system is the widely used system in household wiring. In a ring system, the phase line, neutral line, and earth line from the main switches are taken to all the rooms and then returned to the main switch.

What size wire is used in house wiring?

Indian electricity rules regarding internal wiring: The minimum size of conductor used in domestic wiring must not be of a size less than 1/1.12 mm in copper or 1/1.40 mm (1.5 mm) in aluminum wire. For flexible wires, the minimum size is 14/0.193 mm.

Which wire is best for house wiring?

There are several brands that offer good quality copper wires for house wiring diagrams in India, such as Polycab, Havells, or Finolex. These companies are known for their reliability, durability, and high-quality of products. According to, the best electric wire of the company in India is Polycab.

Which Colour wire is best for your home?

According to the electrical standards of India, red is used for the live (or line) power supply conductor, black for the neutral wire, and green for the protective earth and ground wire. Among red, yellow, and blue, blue-colored light has the shortest wavelength.

How thick is house wiring?

Normally 6 mm² is used for the uprights, 2.5 mm² for the circuits that power supply the sockets or fixed appliances such as the air conditioner, and 1.5 mm² for the light circuits diagram. Continuing with general information, the larger the section of an electric cable, the greater the current flow that will pass.
